Name: High-density long flexible FPC board
Rating: 5.0 (50 reviews)

Product Parameters

Basic parameters

product name:	Flexible printed circuit boards (FPC) - single-sided, double-sided and multilayer
Material:	Polyimide (PI) dielectric materials
product type:	Single-sided FPC, double-sided FPC, multi-layer FPC
Certification standards:	UL, RoHS, SGS, ISO9001, ISO14000, TS16949, IATF

Dimensions and process parameters

Minimum aperture:	0.2mm
Line width/line spacing:	0.1mm / 0.1mm
Supports minimum line width:	0.1mm
Minimum line spacing:	0.1mm
Maximum number of layers:	Multi-layer design, the specific number of layers can be customized according to customer needs.

Electrical properties

Dielectric constant:	Approximately 3.4 (polyimide medium)
Insulation resistance:	High, meets electromagnetic shielding requirements
Signal Integrity:	Excellent, possesses electromagnetic shielding performance

Mechanical properties

Thickness range:	Customized according to customer needs
Folding performance:	Supports multiple folds, flexible design
weight:	Lightweight design, significantly reducing weight compared to traditional rigid boards

Production and Service

production capacity:	55 professional R&D engineers and 400+ production technology staff
service support:	Professional one-stop PCB/FPC solutions, rapid response, and high-reliability supply chain support.

Packaging and Shipping

Packing:	Anti-static and moisture-proof packaging to ensure safe transportation.
Transportation method:	International logistics support ensures timely delivery.

Close

Product Details

Product Introduction

We are a professional supplier offering high-quality flexible printed circuit boards (FPCs) in single-sided, double-sided, and multi-layer configurations, widely used in consumer electronics, medical devices, automotive electronics, and aerospace. Our products utilize polyimide (PI) substrates, providing excellent insulation and electromagnetic shielding capabilities to ensure signal integrity and long-term reliability. With a minimum aperture of 0.2mm and line width/spacing of 0.1mm/0.1mm, they meet the demands of high-density designs. Lightweight design significantly reduces overall weight and simplifies wiring, while folding functionality improves space utilization. Certified by UL, RoHS, SGS, ISO9001, ISO14001, TS16949, and IATF, our products are of stable and reliable quality. With a research and development team of over 55 people and manufacturing personnel over 400, we provide one-stop solutions from design to mass production, helping global customers achieve efficient delivery.

Advantages and features

1. Supports customized single-sided, double-sided, and multi-layer structures to meet complex electronic layout requirements.
2. Made of high-performance polyimide material, it is resistant to high temperatures and bending, and has a longer lifespan.
3. Precision manufacturing process, minimum hole diameter 0.2mm, line spacing 0.1mm, suitable for high-density integration.
4. Meets multiple international environmental and quality standards, ensuring worry-free export.
5. Rapid response and a stable supply chain ensure on-time delivery of foreign trade orders.

Application Scenario

Suitable for applications requiring high space compactness, flexibility, and reliability, such as smartphones, tablets, wearable devices, automotive display systems, industrial control modules, medical imaging equipment, and avionics, serving global electronics manufacturers, OEMs, and EMS contract manufacturers.

Common problem

Q： What aspects are included in the customization service for flexible printed circuit boards?

+

A： We offer customized single-sided, double-sided, and multi-layer flexible PCB structures, supporting minimum hole diameters of 0.2mm, line widths/spacings of 0.1mm, and thickness and number of layers can be tailored to customer needs. Our products utilize high-performance polyimide material and support multiple folding operations. Our comprehensive one-stop solution covers design, manufacturing, and technical support, helping customers achieve personalized electronic product development.

Q： How does your company ensure the production and delivery capabilities of flexible PCBs?

+

A： The company boasts over 55 R&D engineers and more than 400 professional production technicians, equipped with advanced manufacturing equipment and a stable supply chain. We provide one-stop service from design to mass production, responding quickly to customer needs. We employ anti-static and moisture-proof packaging and international logistics support to ensure efficient delivery of flexible PCB products, meeting the timeliness and quality requirements of global customer orders.

Q： What are the main industries and application scenarios for high-density, long-length flexible FPC boards?

+

A： Our high-density, long-length flexible FPCs are widely used in fields requiring high space compactness and flexibility, such as smartphones, tablets, wearable devices, automotive display systems, medical imaging equipment, and avionics. Our lightweight design and multi-layer customization capabilities meet the high-performance needs of complex electronic products across various industries, helping customers enhance their product competitiveness.
